Chargers installed by
QLD Electrical Contractor Lic. 91381
Southport 4215 · The central coast
EV charger installation in Southport, for houses, unit blocks and businesses. Many of the older homes here need the switchboard checked or upgraded before a charger goes in, and we price that in the same quote.
Free site check
Book a Southport site check
Send us your address and a photo of the meter box if you have one. We will tell you what your supply will carry before anyone quotes.
Typical supply
Mostly single phase
What is here
Older houses, walk-up units and high-rise
Switchboards
Boards often older than the house's wiring
Watch for
Long runs from a front-of-house board to rear parking
Most of Southport was built well before home EV charging existed, which is why the switchboard is usually the first thing we check. A lot of the housing west of the highway went up between the fifties and the eighties, when a switchboard only had to run a stove, a hot water service and some lights.
In practice that means two things. The supply is usually single phase, which caps you at around 7kW, and the board itself often has no spare space and no residual current protection on the circuits that matter. Neither of these stops you having a charger installed. Both are priced into the quote, so there are no surprises on install day.
The second Southport habit is where things sit. On the older blocks the meter box is at the front boundary and the car ends up parked at the back or under a carport down the side, so the cable run is long before anything else is decided. We measure the run on site before pricing the job. On an older Southport block it can cost more than the charger itself.
In a unit block or high-rise the electrical work is usually straightforward. The time goes into agreeing with the body corporate where the charger draws its power from and how it is metered back to you. Start that conversation early.
Before we quote
Common on anything built before the nineties. A charger needs its own breaker and its own RCD, and if there is no space the board comes first.
That is enough for most people. Around 40km of range an hour overnight covers several times what an average day uses.
The meter box at the front, the car at the back. The cable run is often the largest single line on a Southport quote, so we measure it on site.
Property types
These are the four kinds of property we work on in Southport, and what each one means before anyone puts a number on it.
Lowset brick and timber through the streets west of the highway. Single phase, an older board, and the parking usually a long way from the meter box. Expect the quote to include board work.
Two and three storey blocks with a common switchboard and a shared car park. Electrically these are straightforward. The work is agreeing with the body corporate where the power comes from and how it is metered.
Basement parking, a large common supply and often an existing rise that can be tapped. Load management matters most in these buildings, because the supply is shared across every bay.
The easiest work in the suburb. Modern boards, sometimes three phase already there, and a garage built close enough to the board that the run is short.
Work we have done in Southport
A job we finished in Southport, with what the property needed and what we did about it.
Residential installSouthport
There was very little usable wall left around the parking area, so placement was most of this job. The Sungrow went on the centre wall between the two garage doors, close to the cars and clear of the door gear. The lead has its own holder underneath instead of lying across the floor.
What we do here
A dedicated charger on its own circuit, sized and wired for it.
Read moreWorkplaces, strata, retail and fleets, with load management across the bays.
Read moreCertified to install and commission it, and it charges most other EVs too.
Read moreTripping, slow, offline or damaged. Every brand we install, plus most other brands.
Read moreFor when 7kW is genuinely not enough. We will tell you if it already is.
Read moreWe cover the suburbs either side of Southport on the same run, so a job next door is an ordinary day for us.
Common questions
Often, yes. A charger needs its own breaker and its own residual current protection, and a lot of the older boards through Southport have room for neither.
We look at the board before quoting and include whatever it needs in the price. A board that gets discovered on install day is how a job turns into a second visit.
It depends on the distance and the route, and on an older Southport block it is often the largest single line on the quote.
We measure it on site, because the cable has to be sized for the distance as well as the load. Send us a photo from the meter box looking towards where the car parks and we can tell you what we are dealing with.
Sometimes, and it has to be available in your street before it can come into the building. Most of the older Southport housing stock is single phase.
Energex is the distribution network for the Gold Coast, so availability and the connection change are decided by them. We check what is available at your address and lodge the application if the upgrade is worth doing.
The electrical work is usually the straightforward part: basement parking, a large common supply and often an existing rise that can be tapped.
The time goes into agreeing with the body corporate where the charger draws its power from and how it is metered back to your lot. We are happy to put the technical detail in writing for the committee so they are deciding on something concrete.
Usually a day when the board has room in it. On the older houses west of the highway the board often needs work first, and the run from a front meter box to parking at the back is long, so allow for more.
A job needing a connection change from the network runs to their timing. We will give you a realistic picture once we have seen your board.
Southport 4215
Send us your address and a photo of the meter box. We will tell you what your supply will carry, what the board needs and what the run to your parking will cost, before anyone quotes you a number.
